LEGRAND BZ200 Wattstopper Plug Load Power Pack Power Pack 120/240/277 VAC, 20 A,

Price $90.81 / EA
Inventory
Available for delivery
Unavailable for pick up Ajax
Qty EA
Manufacturer:LEGRAND
Manufacturer #:BZ200

Description

The BZ-200 power pack switches connected loads On and Off in response to Wattstopper low voltage occupancy sensors. It also provides up to 225mA at 24VDC to power the sensors. This device is constructed with environmentally friendly materials and is RoHS-compliant.

Specifications

Brand Name WattStopper Sub Brand Pass & Seymour
Item Name Plug Load Power Pack Type Power Pack
Voltage Rating 120/240/277 VAC Amperage Rating 20 A
Frequency Rating 50/60 Hz Output Rating 24 VDC, 225 mA
Indicator Type LED Material ABS
Dimensions 3.06 in L x 1.44 in W x 3.07 in H Mounting 1/2 in Knockout
Humidity 5 - 95% Non-Condensing Temperature Rating -4 to 131 °F
Warranty 5 yr Includes Short Circuit and Thermal Protection
Standards UL and cUL Listed: UL244A, UL508 and C22.2 No. 14-10, RoHS Compliant Application Lighting and HVAC Loads
UPC 754182938032
