LEGRAND TR26362GRY Pass & Seymour Tamper-Resistant Decorator, Heavy Duty Straight Blade Duplex Receptacle 20 A, 5-20R Gray

Price $12.77 / EA
Inventory
Available for backorder
Unavailable for pick up Ajax
Qty EA
Manufacturer:LEGRAND
Manufacturer #:TR26362GRY

Description

Receptacle duplex with tamper resistant heavy duty decorator. Dual mechanical shutter system to help prevent insertion of foreign objects. Auto-ground clip assures positive ground. Easily accessed break-off line-contact connecting tab for fast and easy split-circuit wiring. Backed-out tri-drive brass terminal screws for faster installation. Internal screw-pressure-plate back and side wire capability. Two back wire holes for additional wiring flexibility. Corrosion-resistant plated steel strap is locked in to face and back body to resist pulling away from the face/body assembly. 0.032 inch thick brass triple-wipe power contacts. Two drive screws anchor steel strap to back body and face where abrupt removal torque is greatest.

Specifications

Brand Name Pass & Seymour Sub Brand Pass & Seymour
Item Name Straight Blade Duplex Receptacle Type Tamper-Resistant Decorator, Heavy Duty
Grade Specification Size 1.322 L x .833 W x 3.813 H In
Voltage Rating 125 V Amperage Rating 20 A
Number of Poles 2 Number of Wires 3
Connection Type Back and Side Wire NEMA Rating 5-20R
Conductor Size 14-10 AWG Material Nylon
Color Gray Finish Untreated
Frequency Rating 60 Hz Terminal Connection Screw
Dielectric Strength 2000 V Dimensions 33.5 mm W x 21.1 mm D x 96.7 mm H
Mounting Type Wall, Flush Temperature Rating -40 °C to 60 °C
Environmental Conditions UL 94 Requirements, V2 Rated Flammability Standards UL 498, cUL Listed, CSA Certified
Application Commercial Grade UPC 785007277388
